Power Supply: Induced Current Power Supply
Report the RMS Current and Accumulated Current Data by Minutes
High Measuring Accuracy with a Sampling Frequency of up to 3.3 kHz
Self-powered, Free from Batteries or External Wires
Utilize a Sampling Rate of up to 1s for Real-time Monitoring and Quick
Alarm Response
Support Flexible Detachable Design
Support to Connect to a Temperature Sensor via USB for Cable
Temperature Measurement
Equipped with LED Indicator to Indicate Working Status and Alarms
Compliant with Standard LoRaWAN® Gateways and Network Servers
IP30 Rated. Detection Parameter:
RMS Current
Working Frequency:
50~60 Hz
Input current range:
CT103: 2A ~ 250A
Operating Temperature:
-20°C ~ 70°C
Storage Temperature:
-25°C ~ +80°C
Accuracy:
± 1 %
Resolution:
1 mA
